PII Redaction Protocol: Build a Spy-Themed Privacy Dashboard with Quarkus, Presidio, and LangChain4j

Learn how to build a spy-themed web app with Quarkus, Presidio, and LangChain4j that detects and redacts PII from AI-generated content.

Every organization has its secrets. But when those secrets involve personally identifiable information: Names, phone numbers, email addresses, then it's not just spycraft. It's compliance. GDPR. CCPA. Legal landmines.

In this tutorial, you’ll build a privacy-respecting, AI-powered mission control dashboard that detects and redacts sensitive data using open source tooling. Our tech stack includes Quarkus, Microsoft Presidio, LangChain4j, and Ollama. And because security doesn’t have to be boring, we’ll wrap it all in a retro spy theme for good measure.

Your mission, should you choose to accept it, begins now.

The Tech Briefing

Before you’re dropped behind enemy lines, let’s review your tools:

• Quarkus: Your fast-starting Java framework for building REST APIs and full-stack web apps.

• LangChain4j + Ollama: Generates dynamic, AI-written mission briefings using a local LLM.

• Quarkus Presidio: Automatically detects and redacts PII like names, emails, and phone numbers.

• HTML/CSS/JS Frontend: A spy-themed UI for managing mission briefings.

Let’s boot up the command center.

Phase 1: Setting Up Your Field Kit

You’ll need the following before heading out:

• Java 17+

• Maven 3.8.1+

• Podman (Presidio runs as a Dev Service in containers)

• Ollama (Optional: Install from ollama.com and run ollama pull llama3)

With your gear in place, let’s build the project.

Phase 2: Bootstrapping the Mission Control App

Use Maven to generate your Quarkus project with all the right gadgets:

mvn io.quarkus.platform:quarkus-maven-plugin:create \
    -DprojectGroupId=org.mi6 \
    -DprojectArtifactId=mission-control \
    -Dextensions="rest-jackson,quarkus-presidio,quarkus-langchain4j-ollama"
cd mission-control

Phase 3: Connecting to Your AI Handler

LangChain4j needs to know which local LLM to use. Open the project in your IDE and head to src/main/resources/application.properties.

# Ollama LLM configuration
quarkus.langchain4j.ollama.chat-model.model-name=llama3
quarkus.langchain4j.ollama.timeout=120s

Quarkus will either spin it up in a Dev Container or use the local Ollama instance. So you either need Podman/Docker or local Ollama running. This gives us a local, fast, and privacy-safe LLM.

Phase 4: The AI Mission Generator

We’ll use LangChain4j to create mission briefings. Define an interface like so:

package org.mi6;

import dev.langchain4j.service.SystemMessage;
import dev.langchain4j.service.UserMessage;
import io.quarkiverse.langchain4j.RegisterAiService;

@RegisterAiService
public interface MissionGenerator {

    @SystemMessage("""
        You are a mission creator for a top-secret, yet slightly absurd, spy agency.
        Generate a short, funny mission briefing. The mission must include:
        - A fictional contact person's full name.
        - A secret code name for the agent (the user).
        - A specific location (address, city).
        - A date and time for a rendezvous.
        - An email address for contact.
        - A phone number for emergency contact.
        """)
    @UserMessage("Generate a new, unique mission briefing for agent {agentName}.")
    String generateMission(String agentName);
}

Quarkus will generate the implementation at runtime and you can inject it like any other CDI bean.

Phase 5: Backend Intelligence Operations

Let’s wire the first pieces together: detect PII, highlight it for display, and redact it when accepted.

package org.mi6;


import io.quarkiverse.presidio.runtime.Analyzer;
import io.quarkiverse.presidio.runtime.Anonymizer;
import io.quarkiverse.presidio.runtime.model.AnalyzeRequest;
import io.quarkiverse.presidio.runtime.model.AnonymizeRequest;
import io.quarkiverse.presidio.runtime.model.AnonymizeResponse;
import io.quarkiverse.presidio.runtime.model.Mask;
import io.quarkiverse.presidio.runtime.model.RecognizerResultWithAnaysisExplanation;
import io.quarkiverse.presidio.runtime.model.Replace;
import jakarta.enterprise.context.ApplicationScoped;
import jakarta.inject.Inject;
import org.eclipse.microprofile.rest.client.inject.RestClient;

import java.util.Collections;
import java.util.List;

@ApplicationScoped
public class MissionService {

    @Inject
    MissionGenerator model;

    @Inject
    @RestClient
    Analyzer analyzer;

    @Inject
    @RestClient
    Anonymizer anonymizer;

    // Define specific anonymization strategies for our mission briefings
    private static final Replace PERSON_REPLACE = new Replace("[AGENT_NAME]");
    private static final Mask PHONE_MASK = new Mask("*", 4, true); // Mask all but last 4 digits
    private static final Replace EMAIL_REPLACE = new Replace("[REDACTED_EMAIL]");
    private static final Replace LOCATION_REPLACE = new Replace("[CLASSIFIED_LOCATION]");
    private static final Replace DATE_REPLACE = new Replace("[CLASSIFIED_DATE]");
    private static final Replace DEFAULT_REPLACE = new Replace("*****");

    /**
     * A record to hold all the results of our operation.
     * This will be serialized to JSON and sent to the UI.
     */
    public record Mission(
            String originalText,
            String redactedText,
            List<RecognizerResultWithAnaysisExplanation> entities
    ) {}

    /**
     * Generates a new mission, analyzes it for PII, and prepares a redacted version.
     *
     * @return A Mission object containing original text, redacted text, and found entities.
     */
    public Mission generateAndAnalyzeMission() {
        // Step 0: Generate a mission from the Ollama model
        String missionText = model.generateMission("Ethan Hunt");


        // Step 1: Analyze the text to find all PII entities
        var analyzeRequest = new AnalyzeRequest();
        analyzeRequest.text(missionText);
        analyzeRequest.language("en");
        List<RecognizerResultWithAnaysisExplanation> recognizerResults = analyzer.analyzePost(analyzeRequest);

        // Step 2: Define the anonymization request with our custom strategies
        var anonymizeRequest = new AnonymizeRequest();
        anonymizeRequest.setText(missionText);
        anonymizeRequest.analyzerResults(Collections.unmodifiableList(recognizerResults));

        // Apply our specific strategies
        anonymizeRequest.putAnonymizersItem("DEFAULT", DEFAULT_REPLACE);
        anonymizeRequest.putAnonymizersItem("PERSON", PERSON_REPLACE);
        anonymizeRequest.putAnonymizersItem("LOCATION", LOCATION_REPLACE);
        anonymizeRequest.putAnonymizersItem("PHONE_NUMBER", PHONE_MASK);
        anonymizeRequest.putAnonymizersItem("EMAIL_ADDRESS", EMAIL_REPLACE);
        anonymizeRequest.putAnonymizersItem("DATE_TIME", DATE_REPLACE);

        // Step 3: Call the anonymizer to get the redacted text
        AnonymizeResponse anonymizeResponse = anonymizer.anonymizePost(anonymizeRequest);
        String anonymizedText = anonymizeResponse.getText();

        // Step 4: Package everything into our Mission record and return it
        return new Mission(missionText, anonymizedText, recognizerResults);
    }
}

Phase 6: Generate the mission

Now we just need a REST endpoint for the missions:

package org.mi6;

import jakarta.inject.Inject;
import jakarta.ws.rs.GET;
import jakarta.ws.rs.Path;
import jakarta.ws.rs.Produces;
import jakarta.ws.rs.core.MediaType;

@Path("/mission")
public class MissionResource {

    @Inject
    MissionService missionService;

    @GET
    @Path("/new")
    @Produces(MediaType.APPLICATION_JSON)
    public MissionService.Mission getNewMission() {
        return missionService.generateAndAnalyzeMission();
    }
}

Phase 7: Building the Frontend Dashboard

Create a src/main/resources/META-INF/resources directory and add the following files. You can find them in my Github Repository.

• index.html: Spy-themed interface

• style.css: Retro visuals with hoverable PII tags

• app.js: Handles fetching and accepting missions

Each mission briefing shows the full text, with yellow highlights for detected PII. Accepting the mission triggers redaction and replaces sensitive info with <REDACTED> placeholders.

Phase 7: Run the Mission

Fire up the command center:

./mvnw quarkus:dev

If Podman and Ollama are active, Quarkus will:

• Start Presidio via Dev Services

• Connect to your local LLM

• Expose the /mission endpoint

• Serve your frontend at

http://localhost:8080

Click "Request New Mission" and watch as LangChain4j and Presidio work together to generate and scrub a spy briefing in real time.

Final Debrief

With this project, you’ve built more than a toy. You've created a working demonstration of responsible AI and privacy-first development. You now know how to:

• Use Quarkus LangChain4j with a local Ollama model

• Detect and classify PII using Presidio

• Redact sensitive data automatically

• Build an interactive UI to tie it all together

In a world where privacy violations make headlines and compliance fines soar, you've built a digital safehouse.

Nice work, agent. Mission accomplished.
